Canon i-SENSYS MF655Cdw A4 Colour Multifunction Laser Printer with Wifi

Specifications in detail

General Specifications

• Machine Type
  Colour Laser All-In-One
• Available Functions
  Print, Copy and Scan

Print Specifications

• Print Speed
  Single sided: Up to 21 ppm (A4)
  Up to 38 ppm(A5-Landscape)
  Double sided: Up to 12.7 ipm (A4)
• Printing Method
  Colour laser beam printing
• Print Resolution
  Up to 1200 x 1200 dpi
• Warm-up Time
  Approx. 13 seconds or less from power on
• First-Print-Out Time
  Colour approx.: 10.5 seconds or less
  Mono approx.: 10.4 seconds or less
• Printer Languages
  UFRII, PCL 5c2, PCL6
• Fonts
  45 PCL fonts
• Print Margins
  5 mm-top, bottom, left and right
  10 mm-top, bottom, left and right (Envelope)
• Toner Saver Mode
  Yes
• Advanced Printing Features
  Secure Print
  Print from USB memory key (JPEG/TIFF/PDF)
  Print from Cloud (Dropbox, GoogleDrive, OneDrive)1 (PDF/JPEG)
  iOS: AirPrint, Canon PRINT Business app
  Android; Mopria certified, Canon Print Service Plug-in, Canon PRINT Business app

Copy Specifications

• Copy Speed
  • Single sided (A4): Up to 21 ppm
    Double sided (A4): Up to 12.7 ppm
  • First-Copy-Out Time
    ADF (A4):
    Colour Approx. 13.4 seconds or less
    Mono Approx. 11.4 seconds or less
    Platen (A4):
    Colour Approx. 14.5 seconds or less
    Mono Approx. 12.3 seconds or less
  • Copy Resolution
    Up to 600 x 600 dpi
  • Copy Modes
    Text/Photo/Map (Default), Text/Photo/Map (quality), Printed Image, Text
  • Double Sided Copying
    1-sided to 2-sided (Automatic)
  • Multiple Copies
    Up to 999 copies
  • Reduction / Enlargement
    25-400% in 1% increments
  • Other Features
    Frame Erase, Collate, 2 on 1, 4 on 1, ID card copy

  Scan Specifications

  • Standard Type
    Colour
  • Scan Resolution
    Optical: Up to 600 x 600 dpi
    Enhanced: Up to 9600 x 9600 dpi
  • Scan Speed
    Mono: 27ipm (300x600dpi)
    Colour: 14ipm (300x600dpi)
  • Colour Scanning Depth
    24 bit/24 bit (input/output)
  • Greyscales
    256 levels
  • Compatibility
    TWAIN, WIA, ICA
  • Maximum Scan Width
    216mm
  • Scan to E-mail
    TIFF/JPEG/PDF/Compact PDF/Searchable PDF
  • Scan to PC
    TIFF/JPEG/PDF/Compact PDF/Searchable PDF
  • Scan to USB Memory Key
    TIFF/JPEG/PDF/Compact PDF/Searchable PDF
  • Scan to FTP
    TIFF/JPEG/PDF/Compact PDF/Searchable PDF
  • Scan to Cloud
    TIFF/JPEG/PDF/PNG3

  Media Handling

  • Scanner Type
    Platen, ADF
  • Paper Input (Standard)
    250-sheet cassette
    1-sheet manual feed slot
    50-sheet ADF
  • Maximum Paper Input Capacity
    251 sheets
  • Paper Output
    100-sheet
  • Media Types
    Plain paper, Recycled paper, Heavy Paper, Thin paper, Colour paper, Coated paper, Label, Post card, Envelope
  • Media Sizes
    Cassette:
    A4, A5, A5 (Landscape), B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelop (COM10, DL, C5, Monarch), Custom sizes: Min. 76.2 x 127 mm Max. 216 x 355.6 mm.Multi-purpose tray:
    A4, A5, A5 (Landscape), B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelope (COM10, DL, C5, Monarch), Custom sizes: Min 76.2 x 127 mm Max. 216 x 355.6 mm.ADF:
    A4, A5, B5, Legal, Letter, Statement, Custom sizes: Min. 128 x 139.7 mm Max 215.9 x 355.6 mm
  • Media Weights
    Cassette: 60 to 163 g/m² (Up to 200 g/m² with Coated paper)
    Multi-purpose tray: 60 to 163 g/m² (Up to 200 g/m² with Coated paper)
    ADF: 50 to 105 g/m²
  • Double Sided Printing
    Automatic
    Cassette:
    A4, B5, Legal, Letter, Executive, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K
    Custom size – Min. 182 x 257 mm Max. 216 x 355.6 mm
    60 to 200 g/m²

  Interface & Software

  • Interface Type
    USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T, Wireless 802.11b/g/n, Wireless Direct Connection
  • Operating System Compatibility
    Windows® 11 / Windows® 10 / Windows® 8.1 / Server® 2022
    Mac OS X version 10.11 & up
    Linux3
  • Network Protocol
    Print:
    TCP/IP (LPD/Port9100/IPP/IPPS/WSD)
    Scan:
    Push Scan: File: FTP (TCP/IP), SMB3.0 (TCP/IP)
    E-mail/I-Fax: SMTP (send), POP3 (receive)
    Pull Scan: TCP/IPManagement:
    SNMPv1, SNMPv3 (IPv4,IPv6)Security: TLS1.3, IPSec, IP/Mac address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
    Security (wireless):
    Infrastructure Mode:
    WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)
    Access Point Mode:
    WPA2-PSK (AES)
  • Software and Printer Management
    MF Scan Utility,
    Remote User Interface (RUI),
    Department ID Management,
    Toner Status Tool,
    iW Enterprise Management Console: Server-based software for centralised management of a fleet of devices eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics.
    Application Library

  General Features

  • Recommended Monthly Print Volume
    250 – 2,500 pages per month
  • Duty Cycle
    Max. 30,000 pages per month4
  • Processor Speed
    800MHz x 2
  • Memory
    1GB
  • Control Panel
    12.7 cm LCD Colour Touch Screen
  • Dimensions with Trays (W x D x H)
    451 mm x 460 mm x 360 mm
  • Installation Space (W x D x H)
    783 mm x 1,211 mm 789 mm
  • Weight
    Approx. 22.6 Kg
  • Operating Environment
    Temperature: 10 to 30ºC (50 to 86ºF)
    Humidity: 20 to 80% RH (no condensation)
  • Power Source
    220-240V (±10%) 50/60Hz (±2Hz)
  • Power Consumption
    Maximum: Approx. 850 W
    Active printing: Approx. 370W
    Standby: Approx. 11.0 W
    Sleep mode: Approx. 0.8 W
    Typical Electricity Consumption (TEC): 0.19 kWh/week8
    For detailed information relating to Lot26 regulation, please go to: http://www.canon-europe.com/For_Work/Lot26/index.aspx
  • Noise Levels
    Sound Pressure5:
    Active: Simplex 51 dB / Duplex 50 dB
    Standby: InaudibleSound Power5:
    Active: Simplex 65dB or less / Duplex 67 dB or less
    Standby: Inaudible

  Consumables

  • Cartridges
    Cartridge 067 Black (1,350 pages 7)8
    Cartridge 067H Black (3,130 pages 7)8
    Cartridge 067 Cyan (1,250 pages 7)8
    Cartridge 067H Cyan (2,350 pages 7)8
    Cartridge 067 Magenta (1,250 pages 7)8
    Cartridge 067H Magenta (2,350 pages 7)8
    Cartridge 067 Yellow (1,250 pages 7)8
    Cartridge 067H Yellow (2,350 pages 7)8
